Standard HydroFlex Dome Port

This is the same as the domes HydroFlex had designed and fabricated for the Cousteau Society’s 35mm underwater cameras and has been an industry standard for many years with hundreds of credits on major blockbuster films.

Remote Lens Control

The MK5 can be handheld or mounted on an underwater remote head. Utilizing either an ARRI or Preston remote lens control system, the focus puller adjusts iris and zoom and pulls focus from viewing a large monitor from a dry location.

Power and Camera Control

Block batteries supply power to the camera from the surface and can shoot for hours without pulling the housing out of the water. Internal batteries maintain power to the camera when switching topside batteries. With the optional HydroFlex underwater ethernet cable, the assistant has full remote camera control.

Trimming

The HydroFlex Mk5 kit comes with trim weights to be able to reach the ideal buoyancy and balance which is key to camera stability and balance.

Hydroflex Remote AquaCam MK5

The Remote AquaCam housing now has a home on the Gold Coast, Queensland, removing the hefty shipping costs to and from the USA.

Cameras Compatible with Housing

ARRIFLEX

  • Alexa 35
  • Alexa Mini LF
  • Alexa Mini
  • Alexa LF
  • Alexa XT
  • Alexa Plus
  • ARRI 235
  • ARRI 416
  • Amira

Panavision

  • DXL 2

Panasonic

  • Varicam LT
  • Varicam 35

Phantom

  • Phantom Flex​
  • Phantom HD
  • Phantom 4k

Blackmagic

  • USRA MINI PRO 12k
  • URSA MINI 4.6K
  • URSA 4K
  • URSA Broadcast

Sony

  • Venice 2
  • Venice
  • F55
  • F5

RED

  • Dragon
  • Epic
  • Helium
  • Komodo
  • Monstro
  • Raven
  • Scarlet
  • V-Raptor XL
  • V_Raptor
  • Weapon

Weight

22kg Stripped Down

With side mounting plate, without camera, monitor or handles and no additional weights.

44.5kg Neutrally Buoyant Trimmed

This is the weight required to make the housing sink in fresh water. Includes camera, lens, batteries and additional trim weights. (weight required for neutral buoyancy is greater with the addition of extension rings for longer lenses.)

We can arrange to have anything from Hydroflex's inventory shipped out at your expense. Please check out the Hydroflex website to see what they supply.

www.hydroflex.com
